Adjustable Torque Tapping Chuck

ZAT22AKH Air Tapping Tool Handle exhaust Specification: Tapping Capacity Aluminum: 3-12 mm Tapping Capacity Iron: 3-8 mm Free Speed: 150 rpm Air Consumption: 184(6.5) l/min(cfm) Overall Length: 7.87(200) inch(mm) Air Inlet: 1/4 P.T Net Weight: 3.79(1.72) lb(kg) Sound Level: 82 db(A) Model Tapping Capacity Free Speed rpm Air Consumption l/min(cfm) Overall Length inch(mm) Air Inlet P.T Net Weight lbs(kgs) Sound Level dB(A) Aluminum mm Iron mm ZAT22AKH 3-12 [...]

RB24 Robot Arm Specification: New Weight: 10.75 kg Tool Diameter: 56.6 mm Clamping Jaw: Model New Weight kg Tool Diameter mm Clamping Jaw RB16 5.89 38/44 RB24 10.75 56.6

ZAT712AKI 3/8 inch Air Tapping Tool Handle exhaust Specification: Tapping Capacity Aluminum: 1-3 mm Tapping Capacity Iron: 1-3 mm Free Speed: 1000 rpm Air Consumption: 141(5) l/min(cfm) Overall Length: 11.02(280) inch(mm) Air Inlet: 1/4 P.T Net Weight: 1.63(0.74) lb(kg) Sound Level: 77 db(A) Model Tapping Capacity Free Speed rpm Air Consumption l/min(cfm) Overall Length inch(mm) Air Inlet P.T Net Weight lbs(kgs) Sound Level [...]

ZAT23AK Air Tapping Tool Rear exhaust Please specify tapping tool code & chuck standard while ordering. Air Tapping Tool Order Code Reference Model ZAT22AK ZAT19AK ZAT23AK Size Order Code M2 ZAT19AK-2 M3 ZAT22AK-3 ZAT19AK-3 ZAT23AK-3 M4 ZAT22AK-4 ZAT19AK-4 ZAT23AK-4 M5 ZAT22AK-5 ZAT19AK-5 ZAT23AK-5 M6 ZAT22AK-6 ZAT19AK-6 ZAT23AK-6 M8 ZAT22AK-8 ZAT19AK-8 ZAT23AK-8 M10 ZAT22AK-10 ZAT23AK-10 M12 [...]

ZAT415B2 Air Tapping Tool Push to start type Rear exhaust Specification: Tapping Capacity Aluminum: 6-12 mm Tapping Capacity Iron: 6-8 mm Free Speed: 150 rpm Air Consumption: 198(7) l/min(cfm) Overall Length: 9.65(245) inch(mm) Air Inlet: 1/4 P.T Net Weight:3.9(1.77) lb(kg) Sound Level: 82 db(A) Model Tapping Capacity Free Speed rpm Air Consumption l/min(cfm) Overall Length inch(mm) Air Inlet P.T Net Weight lbs(kgs) Sound [...]
