ZRH-132N – 2X Shock Reduced Air Riveting Hammer





Lightweight Riveting Hammer for Precision Applications





The ZRH-132N 2X Shock-Reduced Air Riveting Hammer is engineered for light-duty riveting tasks that demand precision and operator comfort. With its 2X riveting capacity, this pneumatic tool is designed for working with small rivets in thin-gauge materials, making it ideal for use in aerospace, automotive, electronics, and light sheet metal fabrication. Built with a shock-reducing mechanism, the ZRH-132N minimizes vibration and impact transfer to the operator’s hands, reducing fatigue and enhancing safety during extended use. Its balanced, lightweight design ensures excellent maneuverability in tight spaces and detailed applications.





Key Features





• 2X Riveting Power – Optimized for small rivets in thin materials.

• Shock Reduction Design – Lowers vibration and improves operator comfort.

• Compact & Lightweight – Easy to handle for precision riveting.

• Durable Housing – Built with high-quality materials for long service life.

• Feathering Trigger Control – Provides smooth, precise operation.

• Quick-Change Retainer – Fast rivet set replacement for better productivity.





Technical Specifications





• Model: ZRH-132N

• Type: 2X Shock-Reduced Air Riveting Hammer

• Blows per Minute (BPM): ~2,600

• Stroke Length: 2 in. (50 mm)

• Air Inlet: 1/4 in. NPT

• Recommended Air Pressure: 90 PSI (6.2 bar)

• Rivet Capacity: 3/32 in. – 1/8 in. aluminum or mild steel rivets

• Weight: Approx. 4.4 lbs (2.0 kg)

• Vibration Control: Shock-reduced design for extended operator safety





Benefits





Reduced Vibration – Protects operators from fatigue and long-term vibration hazards.
Lightweight & Ergonomic – Comfortable handling for precision work.
Consistent Riveting Performance – Ensures clean, uniform rivet setting.
Durable & Long-Lasting – Designed for demanding industrial use.
Productivity Boost – Quick-change retainer saves valuable work time.





Applications





• Aerospace Manufacturing & Repair – Perfect for interior panels and light structural riveting.

• Automotive Industry – Great for body panels, restoration, and repair work.

• Electronics & Appliances – Riveting thin materials without distortion.

• Light Sheet Metal Fabrication – Clean riveting for small-scale assembly tasks.

• Maintenance & Repair Operations (MRO) – Portable and reliable for on-site riveting.





Why Choose the ZRH-132N?





The ZRH-132N 2X Shock-Reduced Air Riveting Hammer is the ideal tool for light riveting applications requiring precision, reduced vibration, and operator comfort. It delivers reliable performance and long-lasting durability, making it a trusted choice for aerospace, automotive, and light industrial professionals who demand accuracy and comfort in every rivet.

Features





• Designed with the following patents to ensure the best shock reduction and operator’s comfort.
  1) Portable pneumatic tool assembled with module units.
  2) Suspension vibration-reducing means for portable pneumatic tools.
• Alloy steel-made impact parts are heat-treated for durability.
• The spool valve allows slow, heavy blows needed to drive rivets.
• Ergonomic handle with a rubber-made exhaust muffler for added operator comfort.
• An optional patented universal swivel air inlet joint for the best maneuverability of the tool.









• Air inlet tube
• Bumper
• Valve seat
• Air actuating valve
• Auxiliary damping spring
• Ergonomic handle with rubber sleeve



Features





• Patented Shock-Reduced Mechanism.
• Low vibration design to prevent the operator’s injury after long-term use.
• Ergonomic handle with a rubber-made exhaust muffler for added operator comfort.
• An optional patented Universal Swivel Air Inlet Joint for the best maneuverability of the tool.
  Use for the aerospace & general automotive industries, among others.





ZRH-132NK
[ KIT Contents ]

• CA132901 X1
• CA132902 X1
• CA132903 X1
• CA132904 X1
• CA132905 X1
• 192902 Retainer Spring X1





Specification:





• Chisel Shank Opening: 0.401(10.2) inch(mm)
• Bore Diameter: 1/2(12.7) inch(mm)
• Stroke Length: 2-1/4(57.2) inch(mm)
• Blows Per Minute: 2580 bpm
• Operating Air Pressure: 90(6.2) PSI(bar)
• Avg. Air Cons.: 6.71(190) cfm(l/min)
• Net Weight: 2.7(1.2) lbs(kgs)
• Vibration: 6 m/s²
• Rivet Size: 3/32 Steel
• Rivet Size: 1/8 inch(mm)





For ZRH-132P, ZRH-132PAP, ZRH-132S, ZRH-133P, ZRH-133PAP, ZRH-133S, ZRH-134P, ZRH-134PAP, ZRH-134S, ZRH-132N, ZRH-133N, ZRH-134N

• Round 10.18mm
• Material SCM440 Alloy
• Hardness: 48~51º





192902

Optional





192903 132914

















Model	Chisel Shank Opening inch(mm)	Bore Diameter inch(mm)	Stroke Length inch(mm)	Blows Per Minute bpm	Operating Air Pressure psi(bar)	Avg. Air Cons. cfm(l/min)	Net Weight lbs(kgs)	Vibration m/s²	Rivet Size
									Steel	Alum
ZRH-132N	0.401(10.2)	1/2(12.7)	2-1/4(57.2)	2580	90(6.2)	6.71(190)	2.9(1.3)	6	3/32	1/8
ZRH-132NP	0.401(10.2)	9/16(14.3)	2-1/4(57.2)	2580	90(6.2)	6.71(190)	2.9(1.3)	6	3/32	1/8
ZRH-133N	0.401(10.2)	1/2(12.7)	2-7/8(73)	2164	90(6.2)	7.42(210)	2.9(1.3)	6	5/32	3/16
ZRH-133NP	0.401(10.2)	9/16(14.3)	2-7/8(73)	2164	90(6.2)	7.42(210)	2.9(1.3)	6	5/32	3/16
ZRH-134N	0.401(10.2)	1/2(12.7)	3-1/16(77.8)	1740	90(6.2)	7.42(210)	3.7(1.7)	6	3/16	1/4
ZRH-134NP	0.401(10.2)	9/16(14.3)	3-1/16(77.8)	1740	90(6.2)	7.42(210)	3.7(1.7)	6	3/16	1/4
