ZRN1606E – Air Rivet Nut Tool

Reliable Air-Powered Rivet Nut Installation

The ZRN1606E Air Rivet Nut Tool is a powerful and efficient solution for installing rivet nuts with speed and consistency. Engineered for industrial-grade applications, it delivers high pulling force, exceptional durability, and ergonomic comfort, making it ideal for assembly lines and professional workshops.

Key Features

• High Performance Air Power – Provides a strong and consistent force for setting rivet nuts in steel, aluminum, and stainless steel.

• Fast Installation – Optimized for high-cycle production, reducing downtime and increasing productivity.

• Ergonomic Design – A lightweight, balanced construction helps reduce operator fatigue during extended shifts.

• Durable Build – Made with robust components for reliability in demanding industrial environments.

• Easy Operation – Simple to use with intuitive controls, allowing precise rivet nut installation every time.

Technical Specifications

• Model: ZRN1606E

• Tool Type: Air Rivet Nut Tool

• Power Source: Compressed air

• Function: Installation of rivet nuts (various materials)

• Applications: Automotive, aerospace, machinery, electronics, metal fabrication

Benefits

Increased Productivity – Fast cycle times make it perfect for high-volume assembly lines.
Consistent Quality – Ensures uniform rivet nut fastening for secure and reliable joints.
Operator Comfort – Ergonomic design minimizes strain, even in continuous-use environments.
Versatility – Capable of handling a wide range of rivet nut sizes and materials.
Low Maintenance – Built for durability, reducing tool downtime and service costs.

Applications

• Automotive Manufacturing – Secures rivet nuts in body panels, chassis, and components.

• Aerospace Assembly – Ensures strong, lightweight fastening solutions.

• Electronics & Appliances – Ideal for precision fastening in production lines.

• Metal Fabrication – Reliable for fastening across different materials and thicknesses.

Why Choose the ZRN1606E?

The ZRN1606E Air Rivet Nut Tool offers the perfect balance of power, speed, and durability. Whether for industrial production lines or specialized assembly, it guarantees efficient fastening and long-lasting performance, making it a valuable investment for any professional operation.

FOR IMPERIAL SYSTEM

Features

• Features with the most advanced patented digital module to enable operators to know the rivet tool setting capacity instantly under various air supply conditions and the rivet setting cycles performed during their working period.
• It will also remind operators when to do service or maintenance on the tool at the proper intervals.
• It will help to cease the controversy about the warranty issue, especially if the tool has been misused or abused with abnormally high air pressure, which exceeds the design specification.
• Built with patented “Module units assembled in composite clam shell housing” for the ease of tool service.
• Forged and heat-treated aluminum alloy made Hydraulic Section for the best rigidity.
• Easy-to-adjust head and nut designed for obtaining the most effective stroke.
• Ergonomic texture-coated composite housing for the operator’s comfort.
• The swivel air inlet design enhances maneuverability.

• Aluminum Alloy Forged Hydraulic Section
• Adjustable Stroke
• Air Motor
• Air Actuating Module
• Composite Clam Shell Housing
• AAA Battery Port
• LCD Module
• USB Port

Specification:

• Traction Power: 3500(1600) Ibf(kgf)
• Stroke Length: 6 mm
• Net Weight: 4.9(2.2) lbs(kgs)
• Rivet Nut / Rivet Stud Setting Capacity: #8-32~3/8″-16 rivet nut in Hex./Steel 1/2″-13 need 100psi/7 bar operating pressure

DO NOT apply air pressure over 110 psi / 7.5 bar to these tools.
*Please refer to the blind rivet specification to ensure the tensile strength is lower than the traction power of the model you select.
