ZSB3000 Spring Balancer





The ZSB3000 Spring Balancer is a medium-duty ergonomic load-balancing device designed to improve tool handling efficiency, operator comfort, and safety in production, assembly, and maintenance environments. It counterbalances the weight of suspended tools or equipment, allowing them to be operated in a nearly weightless condition. This reduces fatigue, enhances precision, and improves workplace productivity. Constructed with a precision coil spring system, reinforced steel housing, and an integrated safety mechanism, the ZSB3000 provides stable performance, consistent tension control, and long service life. It is ideal for supporting pneumatic tools, torque wrenches, electric screwdrivers, and other suspended devices used in repetitive industrial tasks.





Key Features





• Load Capacity up to 30 kg – Supports medium-weight tools with smooth and balanced counterforce.

• Adjustable Spring Tension – Easily fine-tuned to match the exact weight of each tool.

• Durable Steel Housing – Heavy-gauge structure ensures rigidity and long-term protection in harsh environments.

• Smooth Vertical Motion – Provides steady tool movement across the full stroke without rebound or jerk.

• Built-in Safety Lock – Prevents accidental tool drop in the event of spring or cable failure.

• High-Tensile Steel Cable – Braided stainless-steel wire ensures safe and reliable suspension.

• Compact Installation – Suitable for overhead use in production cells or tight work areas.

• Cable Stopper Adjustment – Allows the working stroke to be tailored for operator comfort.

• Low Maintenance – Sealed spring housing minimizes wear and contamination.

• Corrosion-Resistant Finish – Powder-coated surface resists moisture and abrasion.





Applications





The ZSB3000 Spring Balancer is suitable for a wide range of industrial and assembly operations, including:





• Automotive and mechanical assembly lines

• Welding and fabrication stations

• Electronics or appliance manufacturing

• Maintenance and repair workshops

• Packaging and production lines





It is ideal for supporting torque tools, impact wrenches, drills, riveters, grinders, and other suspended equipment.





Performance Advantages





• Ergonomic Efficiency – Reduces operator fatigue and increases precision by eliminating resistance to tool weight.

• Safety Assurance – The internal locking system prevents sudden load drop, protecting both the operator and the tool.

• Reliable Operation – Consistent spring tension ensures smooth and stable tool positioning.

• High Durability – Precision-wound coil springs and reinforced steel casings ensure a long service life.

• Improved Productivity – Allows faster, fatigue-free operation in continuous-duty environments.

• Low Maintenance – Factory-sealed lubrication minimizes downtime.





Technical Specifications





• Model: ZSB3000

• Load Capacity: 20 – 30 kg (adjustable range)

• Cable Travel: Approx. 1.5 m (varies with installation height)

• Housing Material: Reinforced steel with powder-coated finish

• Cable Material: Stainless-steel wire rope, high-tensile grade

• Safety Mechanism: Internal ratchet lock and secondary safety hook

• Spring Type: High-tension coil spring, sealed and pre-lubricated

• Mounting: Overhead suspension hook or bracket

• Operating Temperature: 0 °C – +50 °C

• Maintenance: Periodic visual inspection of cable and tension system recommended





The ZSB3000 Spring Balancer offers a dependable and ergonomic solution for handling medium-weight tools in continuous production or repair environments. Its adjustable tension control, safety features, and heavy-duty construction deliver long-term reliability with minimal maintenance. Ideal for assembly and industrial workplaces that prioritize operator comfort, safety, and efficiency, the ZSB3000 ensures smooth, balanced operation and stable tool positioning throughout every production cycle.





Features





• Cost-efficient, practical, and compact. It uses a rotatory Adjusting Cover for more effortless tension adjustment without burden.
• Fast and convenient installation. Additionally, anti-falling steel wire mounting holes are provided, which must be installed to prevent failure at the original mounting location.
• The housing is made of a rustproof iron shell. The steel wires and nylon ropes are available as an option. Furthermore, a ball-shaped damper can also prevent the tool from reaching a fixed height during its recovery stroke.
